RY Hot Oil Circulation Pump

Category:

Product Description

RY Hot Oil Circulation Pump adopts the self-heat-radiating structure, change the traditional water cooling structure, make it more simple, small volume, economy operation cost, good performance, reliable operation.
Structure Characteristics:

1. Basic structure is single stage single suction cantilever feet support, pump suction is axial inhaled, discharge center vertical, and installed in a same base with motor.

2. RY Hot Oil Circulation Pump supported by double ball bearing, front end lubricated by lubricating oil, back end lubricated by grease, a guide tubing in the middle, to observe the conditions of sealing at any time and recovery of heat conduction oil.

3. Hot oil pump shaft seal:
(1) With the combination of packing seal and mechanical seal, packing seal use high temperature resistant packing, has the good thermal adaptability, while mechanical seal adopts high mechanical strength and wear resistance, good hard alloy material, which guarantees the sealing performance under high temperature conditions.
(2) Adopts imported polyethylene (PTFE) as lip shape seal, make the sealing performance much better, seal reliability of 25 times than rubber seal, and with very strong corrosion-resist ability.

Model Capacity
m 3 /h
Lift
m
Speed
r/min
Power kw Efficiency
η%
Motor-Y
Shaft
power
Power
Distribution
RY50-32-160 12.5 30 2900 1.90 3.0 57 100L
RY50-32-200 18 40 2900 3.92 5.5 50 132Sl
RY50-32-200A 16 32 2900 3.35 4 42 112M
RY50-32-250 12.5 80 2900 6.2 11 44 160Ml
RY65-50-160 20 32 2900 3.17 5.5 55 132S1
RY65-40-200 30 48 2900 6.3 7.5 62 132S2
RY65-40-200A 25 35 2900 4.0 5.5 59 132S1
RY65-40-250 25 80 2900 10.3 15 53 160M2
RY65-40-250A 20 51 2900 5.67 7.5 49 132S2
RY65-40-315 25 125 2900 18.9 30 45 200L1
RY65-40-315A 22.5 100 2900 15.3 22 40 180M
RY80-50-200 50 50 2900 9.7 15 70 160M2
RY80-50-200A 45 40 2900 7.8 11 63 160M1
RY80-50-200B 40 32 2900 6.37 7.5 55 132S2
RY80-50-250 50 80 2900 17.1 22 58 180M
RY80-50-250A 43 60 2900 12.8 15 55 160M2
RY80-50-315 50 125 2900 30.4 45 56 225M
RY80-50-315A 45 100 2900 23.6 30 52 200L1
RY100-65-200 100 50 2900 18.4 22 74 180M
RY100-65-200A 94 44 2900 16 22 70 180M
RY100-65-200B 87 38 2900 13.8 15 65 160M2
RY100-65-200C 80 32 2900 11.8 15 59 160M2
RY100-65-250 100 80 2900 32.06 37 68 200L2
RY100-65-250A 95 72 2900 29 37 64 200L2
RY100-65-250B 90 65 2900 26.2 30 61 200L1
RY100-65-250C 85 50 2900 20.3 30 57 200L1
RY100-65-315 100 125 2900 50.06 75 68 280S
RY100-65-315A 95 113 2900 45.23 55 64.63 250M
RY100-65-315B 90 100 2900 40.5 55 60.50 250M
RY100-65-315C 82 84 2900 34.76 45 54 225M
RY125-100-200 200 50 2900 35.4 45 77 225M
RY125-100-200A 178 40 2900 26.6 37 73 200L2
RY125-100-250 200 70 2900 47 55 80 250M
RY125-100-250A 190 63 2900 41.6 55 78 250M
RY125-100-250B 180 57 2900 37.9 45 74 225M
RY125-100-250C 170 51 2900 32.15 45 72 225M
RY125-100-250D 150 70 2900 40 45 70 225M
RY150-150-200 350 50 2900 60 75 80 280S
RY150-150-200A 313 40 2900 45 55 76 250M
RY200-150-400 350 50 1450 61.8 75 78 280S
RY200-150-400A 330 45 1450 52.8 75 77 280S
RY250-200-400 500 50 1480 86.2 110 79 315S
RY250-200-500 500 80 1480 136 160 76.5 315M
RY250-200-500A 400 50 1480 75 90 73 280M
